MODE: AM/FM
FREQUENCY RANGE: 28.315-28.755–UNMODIFIED
FREQUENCY STABILITY: .001%
13.8 VOLTS DC
LARGE ILLUMINATED METER INDICATES RELATIVE OUTPUT
POWER, RECEIVER SIGNAL STRENGTH, SWR & AM MODULATION LEVEL,
OUTPUT POWER: NON MODIFIED: AM/FM--------10 TO 65
WATTS
IMAGE REJECTION: -50db
RECEIVER SENSITIVITY: AM 0.5 MICRO VOLTS
: FM 0.25 MICRO VOLTS
HUM & NOISE: 40db
CONTROLS:
VOLUME-ON/OFF, SQUELCH, MIC GAIN, RF GAIN, ECHO, TIME
, TALK-BACK, RF POWER, BAND SELECTOR, SWR/MOD/PWR SWITCH, MODE
SWITCH, +10KC-NB/ANL/NB/ANL/ OFF SWITCH, BRIGHT/MED/DIM SWITCH, ECHO OFF
SWITCH
FUNCTIONS & AMENITIES:
STANDARD 4 PIN MIC CONN.
HIGH POWER DC POWER PLUG
VARIABLE RF OUTPUT POWER, ECHO WITH TIME DELAY,
SWR METERING SYSTEM, TALK-BACK, +10KC, PA. JACK, EXT. SPEAKER JACK. MICRO
COOLING FAN. AUTOMATIC SWR CIRCUIT & HIGH SWR WARNING LIGHT.
FACEPLATE IS BACKLIT IN GREEN & BLUE.
SIZE: 7 3/4*2 7/8*10 1/4 DIMENSIONS ARE IN INCHES
