MODE: AM/FM
FREQUENCY RANGE: 28.065-28.505–UNMODIFIED
FREQUENCY TOLERANCE: .005%
FREQUENCY STABILITY: .001%
13.8 VOLTS DC POSITIVE OR NEGATIVE GROUND
LARGE ILLUMINATED METER INDICATES RELATIVE OUTPUT
POWER, RECEIVER SIGNAL STRENGTH, & SWR.
OUTPUT POWER: NON MODIFIED: AM/FM—7 WATTS
CLASS B MODULATION
RECEIVER SENSITIVITY: AM-.5 MICRO VOLTS
FM-1.0 MICRO VOLTS
IMAGE REJECTION: MORE THAN 65db
ADJACENT CHANNEL REJECTION: 60db
CONTROLS:
VOLUME-ON/OFF, MIC/RF GAIN, DIMMER/RF POWER, BAND
SELECTOR A-F, CLARIFIER, AM/F/PA, NB+/NB/OFF, RB/OFF, 10KC /OFF, CHANNEL
SELECTOR.
STANDARD 4 PIN MIC PLUG & 3 PIN PWR JACK
FUNCTIONS:
VARIABLE OUTPUT POWER, 5 DIGIT FREQUENCY COUNTER,
ROGER BEEP, 10KC FOR RC CHANNELS.
NO ECHO, NO TALK BACK
SIZE: 2-3/8 H, 7-7/8 W, 9-1/4 D DIMENSIONS ARE IN INCHES
