MODE: AM/FM
FREQUENCY RANGE: 28.315-28.755- UNMODIFIED
FREQUENCY STABILITY: .001%
FREQUENCY TOLERANCE: .005%
13.8 VOLTS DC POSITIVE OR NEGATIVE GROUND
LARGE ILLUMINATED METER INDICATES RELATIVE OUTPUT
POWER, RECEIVER SIGNAL STRENGTH, & SWR
OUTPUT POWER: NON MODIFIED: AM/FM-----7 WATTS
CLASS B MODULATION
RECEIVER SENSITIVITY: AM-.05 MICRO VOLTS
FM-1.0 MICRO VOLTS
ADJACENT CHANNEL REJECTION: 60db AM
IMAGE REJECTION: MORE THAN 65 db
CONTROLS:
VOLUME-ON/OFF/SQUELCH, MIC GAIN/RF GAIN, ECHO/TONE,
DIMMER/RF POWER, BAND SELECTOR A-D, CLARIFIER, HI-LO BAND SWITCH, ON/OFF
ROGER BEEP, PA/A/FM, ON/OFF NOISE BLANKER, +10KC SWITCH
STANDARD 4 PI MIC CONN & 3 PIN PWR JACK
FUNCTIONS:
VARIABLE RF OUTPUT POWER, ROGER BEEP, ECHO, TALK BACK,
5 DIGIT FREQUENCY COUNTER, + 10KC FOR RC CHANNELS, CLARIFIER.
SIZE: 2-3/8 H, 7-7/8 W, 9-1/4 D DIMENSIONS ARE IN INCHES
