MODE: AM/FM
FREQUENCY RANGE: 28.315-28.755–UNMODIFIED
FREQUENCY STABILITY: .005%
13.8 VOLTS DC
LARGE ILLUMINATED METER INDICATES RELATIVE OUTPUT
POWER, RECEIVER SIGNAL STRENGTH & SWR.
OUTPUT POWER: NON MODIFIED: AM/FM--------10 WATTS
IMAGE REJECTION: -60db
RECEIVER SENSITIVITY: AM/FM 1MICRO VOLT
CONTROLS:
VOLUME-ON/OFF/SQUELCH, MIC GAIN/RF GAIN/DW, DIMMER/RF
POWER, ECHO/SPEED/SWR CAL/CLARIFIER, BAND SELECTOR A-H, ECHO/VC/R1/R2/R3/R4,
PA/AM/FM, ROGER BEEP/OFF/SWR, OFF/NOISE BLANKER/FREQ DISPLAY OFF, 6/19/21
PRE ASSIGNED CHANNELS, +10KC SWITCH, CHANNEL SELECTOR.
STANDARD 4 PIN MIC CONN. & 3 PIN POW JACK
FUNCTIONS:
VARIABLE OUTPUT POWER, DUAL WATCH, VARIABLE LED DIMMER,
ECHO,
5 STAGE VOICE CONTROL, ROGER BEEP, SWR SYSTEM, 3 PRE
TUNED CHANNELS, 5 DIGIT FREQUENCY COUNTER, +10KC FOR RC CHANNELS.
SIZE: 2-3/8 H, 7-7/8 W, 9-1/4 D DIMENSIONS ARE IN INCHES
