MODE: AM/FM/SSB
FREQUENCY RANGE: 28.065 to 28.505MHZ –UNMODIFIED
FREQUENCY STABILITY: .005%
13.8 VOLTS DC
LARGE ILLUMINATED METER INDICATES RELATIVE OUTPUT
POWER, RECEIVER SIGNAL STRENGTH & SWR.
OUTPUT POWER: NON MODIFIED: AM/FM--------10 WATTS
: SSB-------------25 WATTS
MODULATION: CLASS B
SSB CARRIER SUPPRESSION: 55dB
UNWANTED SIDEBAND: 50Db
IMAGE REJECTION: -65db
RECEIVER SENSITIVITY: AM 0.5 MICRO VOLT FOR 10dB
: FM 1.0 MICRO VOLT FOR 20 dB
: SSB 0.25 MICRO VOLTS FOR 10dB
RECEIVER SELECTIVITY: AM/FM 6dB @ 3KHZ, 50dB @ 9KHZ
: SSB 6dB @ 2.1KHZ, 60dB @ 3.3KHZ
ADJACENT CHANNEL REJECTION: 60dB AM/FM, & 70dB
SSB
CLARIFIER RANGE: COURSE UNLOCKED +/-5KHZ
: FINE LOCKED +/- 1KHZ
CONTROLS:
VOLUME ON/OFF/ SQUELCH, MIC GAIN/RF GAIN, ECHO/TONE,
BAND SELECTOR, MODE-AM-FM-USB-LSB, CLARIFIER-FINE/COURSE, CHANNEL SELECTOR,
RF POWER SWITCHABLE 3 STAGE, OFF/ANL/NB, ROGER BEEP SWITCHABLE, 10KC SWITCH
AMENITIES: 3 STAGE OUTPUT POWER ON AM, ECHO, ROGER BEEP, FINE/COURSE CLARIFIER, 10KC ADJUSTMENT FOR RC CHANNELS.
STANDARD 4 PIN MIC CONN. & 3 PIN POWER JACK, PA JACK, EXTERNAL SPEAKER JACK, FREQUENCY COUNTER SOCKET FOR OPTIONAL COUNTER.
SIZE: 2-3/8 H, 7-7/8 W, 9-1/4 D DIMENSIONS ARE IN INCHES
